Carbon Brush Holders

Double-leg carbon brush holder

Part No. Double-leg carbon brush holder

Double-leg carbon brush holder is a heavy-duty brush holder assembly with dual mounting flanges for installing one carbon brush. It adopts high insulation phenolic resin or reinforced plastic housing fitted with stainless steel constant force spring. The double-leg structure provides stronger mounting stability against heavy vibration. It maintains reliable contact between carbon brush and commutator or slip ring. Perfect for industrial DC motors, generator slip rings and wind turbine earthing a

Material	High-strength phenolic resin / reinforced engineering plastic, high dielectric strength and heat res
Dimensions	Double leg mounting design
Application	Industrial DC motors, generator slip ring assemblies, wind turbine grounding systems, traction motors, large rotating machinery. Ideal for heavy vibration environments where stable fixing is required, widely used for motor maintenance and spare part repla
Voltage	Low and medium voltage rotating equipment
Current Density	Suitable for low to medium current continuous duty operation
Lead Type	Terminal lug or flexible shunt lead optional
Spring	Built-in stainless steel constant force spring, delivers consistent brush contact pressure

Request a Quote Related Products

48h Sample Dispatch 60+ Countries Served Datasheet Included

Technical Specifications

Product Name	Double-leg carbon brush holder
Product Type	Carbon Brush Holder Assembly
Housing Material	Phenolic Resin / Reinforced Engineering Plastic
Spring Type	Stainless Steel Constant Force Spring
Brush Quantity	1 Carbon Brush
Mounting Structure	Double Leg Flange Mounting
Terminal Material	Copper Alloy / Silver Plated Copper
Connection Method	Screw Terminal
Main Application	DC motor, generator slip ring, wind turbine grounding, heavy rotating machinery
Key Features	Strong mounting stability, anti-vibration, durable, custom sizes available
Usage	Heavy-duty rotating equipment maintenance & replacement spare part

Description

Double-leg carbon brush holder is a robust brush holder assembly designed with dual mounting legs for fixed installation of single carbon brush. The double flange mounting structure greatly improves stability, making it suitable for equipment operating under strong vibration conditions. The holder housing is constructed from high-temperature phenolic resin or reinforced engineering plastic, featuring excellent insulation, heat resistance and mechanical strength. Equipped with stainless steel constant force spring, it keeps uniform pressure on carbon brush during long continuous operation, reducing electrical sparking and minimizing wear of commutator and slip ring. Copper or silver-plated copper terminals ensure outstanding electrical conductivity and low heat generation. This double leg brush holder is commonly used for generator slip rings, large DC industrial motors and wind turbine shaft grounding systems. Custom brush slot sizes are available to match various carbon brush specifications. It serves as a reliable replacement spare part for heavy-duty rotating machinery maintenance.
