Electric Drill Motor Carbon Brush Holder For RS775 RS755 RS750 RS 775 750 Motor

Need a custom part? Send us your drawing, sample or part number — we'll reply with a quotation within 24 hours. Request a quote →

Carbon Brush Holders

Electric Drill Motor Carbon Brush Holder For RS775 RS755 RS750 RS 775 750 Motor

Part No. RS775 RS755 RS750 RS 775 750

Electric drill motor carbon brush holder for RS775 / RS755 / RS750 DC motors — spring-loaded brush holder with terminals for power-tool commutator duty (drills, impact wrenches, screwdrivers), 12–48 V class. Verify brush box size and motor voltage per part.

Application	Brush holder for RS775 / RS755 / RS750 DC motors — the standard brush gear in electric drills, impact wrenches, screwdrivers and other power tools: holds the brushes on the commutator under spring pressure for high-speed, frequent start/stop duty. Hol
Voltage	12–48 V DC class typical for RS775-family motors (market listings: 18 V / 25

Compatible Models

RS775 DC motor (electric drill / power tool class) RS755 DC motor RS750 DC motor RS-775 / 750-series motor end-bell brush gear (18 V / 25 V / 48 V classes) Power tools using RS550/RS775-family motors (drills impact wrenches — verify per tool)

Request a Quote Related Products

48h Sample Dispatch 60+ Countries Served Datasheet Included

Technical Specifications

Electric Drill Motor Carbon Brush Holder — RS775 / RS755 / RS750
Specification	Value
Product Type	Carbon brush holder for RS775-family DC motors
Compatible Motors	RS775 / RS755 / RS750; RS-775/750-series
Application	Electric drills, impact wrenches, screwdrivers (power tools)
Voltage Class	12–48 V DC (18 V / 25 V / 48 V per market)
Material	Not specified — confirm (brass/copper alloy typical)
Brush Box Size	Not specified — confirm (W × T)
Spring	Spring-loaded (typical) — confirm type/force
Terminals	For brush circuit connection — confirm spacing

* RS775-family fitment and voltage class from power-tool market data. Holder dimensions and material pending confirmation.

Compatible Models

This Electric Drill Motor Carbon Brush Holder For RS775 RS755 RS750 RS 775 750 Motor is designed as a direct replacement for the following machine models and series:

Not sure if it fits your machine? Send us your equipment model, motor type or original part number — our engineers will confirm compatibility and advise the correct grade. Ask an engineer →

Description

Overview

Carbon brush holder for RS775 / RS755 / RS750 DC motors — the brush gear that keeps carbon brushes on the commutator under spring pressure in electric drills, impact wrenches and screwdrivers. Designed for high-speed, frequent start/stop power-tool duty.淘宝
