Carbon Brush Holders

Single-leg carbon brush holder‌

Part No. Single-leg carbon brush holder‌

Single-leg carbon brush holder is a compact single mounting foot brush holder assembly for one carbon brush. Made of high insulation phenolic resin or reinforced plastic housing with stainless steel constant force spring. Single leg flange design saves installation space, easy for field assembly. It keeps steady contact pressure between carbon brush and slip ring / commutator. Suitable for wind turbine earthing brushes, small DC motors, generator slip rings and other rotating machinery maintenan

Material	- Housing: High-strength phenolic resin / reinforced engineering plastic, high insulation & heat res
Dimensions	- Structure: Single leg mounting design - Single brush cavity, custom brush slot size available - Mo
Application	Industrial DC motors, wind turbine grounding brushes, slip ring assemblies, traction motors, power generator, rotating machinery. Widely used for equipment requiring compact single carbon brush installation, motor overhaul and spare part replacement.
Voltage	Low and medium voltage rotating equipment
Current Density	Suitable for low to medium current continuous operation
Speed	Designed for continuous rotating speed of generators and industrial motors
Grade	Industrial OEM replacement grade
Connection	Screw terminal connection
Lead Type	Terminal lug or flexible shunt lead optional
Spring	Built-in stainless steel constant force spring, maintains stable brush pressure

Request a Quote Related Products

48h Sample Dispatch 60+ Countries Served Datasheet Included

Technical Specifications

Product Name	Single-leg carbon brush holder
Product Type	Carbon Brush Holder Assembly
Housing Material	Phenolic Resin / Reinforced Engineering Plastic
Spring Type	Stainless Steel Constant Force Spring
Brush Quantity	1 Carbon Brush
Mounting Structure	Single Leg Flange Mounting
Terminal Material	Copper Alloy / Silver Plated Copper
Connection Method	Screw Terminal
Main Application	DC motor, wind turbine grounding, generator slip ring, rotating machinery
Key Features	Compact size, space-saving, simple installation, vibration resistance
Usage	Industrial rotating equipment maintenance & replacement spare part

Description

Single-leg carbon brush holder is a lightweight, space-saving single foot brush holder assembly used to mount one carbon brush on commutators or slip rings. Its single leg flange mounting structure greatly reduces occupied installation space, ideal for compact machinery where multi-leg holders cannot fit. The main housing adopts high-temperature insulated phenolic resin or reinforced engineering plastic, providing excellent dielectric strength and resistance to vibration and heat. Equipped with stainless steel constant force spring, it delivers consistent pressure on carbon brush during long-term running, minimizing sparking and reducing wear of commutator and slip ring. Copper or silver-plated copper terminals guarantee reliable electrical conductivity and low heat buildup. This single leg brush holder is widely applied in wind turbine shaft grounding systems, small DC motors, auxiliary generators and other rotating equipment. Custom dimensions for brush slot are available to match different carbon brush sizes. It is a popular replacement spare part for industrial motor and wind farm maintenance.
